Specification
Camera |
||
---|---|---|
Image Sensor: |
1/3″ Progressive Scan CMOS |
|
Signal System: |
PAL/NTSC |
|
Min. Illumination: |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR |
|
Shutter time: |
1/3 s to 1/100,000 s |
|
Slow shutter: |
Support |
|
Lens: |
2.8 mm @ F1.6: horizontal FOV: 103°, vertical FOV: 58°, diagonal FOV: 123°4 mm @F1.6: horizontal FOV: 83°, vertical FOV: 45°, diagonal FOV: 99°6 mm @F1.6: horizontal FOV: 51°, vertical FOV: 29°, diagonal FOV: 58°8 mm @F1.6: horizontal FOV: 39°, vertical FOV: 22°, diagonal FOV: 45° |
|
Lens Mount: |
M12 |
|
Adjustment Range: |
Pan: 0° to 360°, tilt: 0° to 100°, rotate: 0° to 360° |
|
Day& Night: |
IR cut filter with auto switch |
|
Wide Dynamic Range: |
120 dB |
|
Digital noise reduction: |
3D DNR |
|
Focus: |
Fixed |
Compression Standard |
||
---|---|---|
Video Compression: |
H.265+/H.265/H.264+/H.264/MJPEG |
|
Video bit rate: |
256Kbps~16Mbps |
|
Triple Streams: |
Yes |
Image |
||
---|---|---|
Max. Image Resolution: |
2688 × 1520 |
|
Frame Rate: |
50Hz:25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080)60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080) |
|
Sub Stream: |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
|
Third Stream: |
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
|
Image Enhancement: |
BLC/3D DNR/ROI/HLC |
|
Image Settings: |
Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser |
|
Target Cropping: |
No |
|
ROI: |
1 fixed region for main stream and sub-stream |
|
Day/Night Switch: |
Day/Night/Auto/Schedule |
Network |
||
---|---|---|
Network Storage: |
Support micro SD/SDHC/SDXC card (128G), flash memory , ANR |
|
Alarm Trigger: |
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
|
Protocols: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP?, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
|
General Function: |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacymask, Watermark, IP address filtering |
|
System Compatibility: |
ONVIF (Profile S, Profile G),ISAPI |
Interface |
||
---|---|---|
Communication Interface: |
1 RJ45 10M / 100M Ethernet interface |
|
On-board storage: |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
|
Reset Button: |
Yes |
Smart Feature-set |
||
---|---|---|
Behavior Analysis: |
Line crossing detection, intrusion detection |
|
Line Crossing Detection: |
Cross a pre-defined virtual line |
|
Intrusion Detection: |
Enter and loiter in a pre-defined virtual region |
|
Recognition: |
Face Detection |
General |
||
---|---|---|
Operating Conditions: |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)Humidity 95% or less (non-condensing) |
|
Power Supply: |
12 VDC ± 25%, PoE (802.3af Class3) |
|
Power Consumption: |
-I5:12 VDC, 0.6A, max. 7.5WPoE (802.3af, 37V to 57V), 0.2A to 0.1A, max. 9.5W-I8:12 VDC, 0.95A, max. 11.5WPoE (802.3af, 37V to 57V), 0.35A to 0.1A, max. 12.5W |
|
Weather Proof: |
IP67 |
|
IR Range: |
-I5: up to 50 m; -I8: up to 80 m |
|
Dimensions: |
Camera: Φ 105 × 299.7 mm (Φ 4.1″ × 11.8″)Package: 386 × 156 × 155 mm (15.2″ × 6.14″ × 6.1″) |
|
Weight: |
Camera: Approx. 1180 g (2.6 lb.)With Package: Approx. 1700 g (3.7 lb.) |
